CS875-575-375-275-175 Installers Manual with CS5500 keypad B.12.9
12.5 Technical specifications
12.1.8.1.1 Opening A menu option that sets the time at which the selected schedule enters the
open state.
12.1.8.1.2 Closing A menu option that sets the time at which the selected schedule enters the
closed state.
12.1.8.1.3 Active A menu option that specifies the days of the week that the selected schedule is
active.
12.1.8.1.3.1 Disable on Holidays A menu option that activates the holidays feature. The selected schedule is not
active on the dates specified in Date of holidays.
12.1.9 Date of holidays A menu option that sets the dates of holidays. If the holidays feature
(12.1.8.1.3.1) has been enabled, no schedules are active on these dates. Up to
eight holidays per month can be specified.
12.1.10 Reset Reader Address A menu option that wipes the proximity reader’s module number so that the
reader can be learned in again on the control panel.
12.1.11 Model A menu option that displays the current model of the proximity reader.
12.1.12 Version A menu option that displays the current software version of the proximity
reader.
12.1.13 Default Settings A menu option that defaults the selected proximity reader to factory defaults.
Power supply specifications
Power supply voltage 13.8V ± 2%
Consumption - Standby 40 mA at 13.8V ± 2%
Consumption – Maximum 110 mA at 13.8V ± 2%
General feature specifications
Reader Size Dimensions (width x height x depth) 35x118x15 mm
Environmental Operating temperature +0° C to + 40 °C
Humidity Max 93% non condensing
Shipping Weight 115 g
Location Term Definition
