CS875-575-375-275-175 Installers Manual with CS5500 keypadB.12.2
12.2.1 Wiring the CS1700 proximity reader
12.2.2 Enrolling the CS1700 proximity reader
Unlike most CSx75 expanders, the CS1700 proximity reader determines its own address after installation is
complete. It is the first step in programming the reader. To enroll a reader follow the steps below:
1. Wire the CS1700 proximity reader to the system.
2. Enter programming mode.
3. When you are in the installer menu, scan a card at the reader to initiate addressing mode.
4. An address is assigned almost instantly and the reader beeps back its address as shown in Table 12-2: CS1700
proximity reader addresses.
5. Select Installer Menu>Enrol Modules>Enrol to enrol the CS1700 proximity reader. The enrolling process
takes about 12 seconds. User codes are not accepted during the enrolling process.
Table 12-1: CS1700 proximity reader terminal connections
Wire Description
Green (data) Connect to the control panel DATA terminal. This wire is the data-signalling terminal to all
the devices on the bus.
Black (com) Connect to the control panel COMMON terminal. This wire supplies the common side of
the power to the CS1700 proximity reader.
Red (pos) Connect to the control panel AUX POWER + terminal. This wire supplies power to the
CS1700 proximity reader.
White (egress) This is an optional EGRESS input. To use this feature, connect the normally open egress
switch between this terminal and COM. If this feature is not used, there is no need to
connect this wire.
Blue (output) This is an optional open-collector OUTPUT. To use this feature, connect the coil contacts
of a relay between this terminal and AUX POWER +.
Table 12-2: CS1700 proximity reader addresses
Beeps Address Beeps Address
11139121
2 114 10 122
3 115 11 123
4 116 12 124
5 117 13 125
6 118 14 126
7 119 15 127
8 120
