185
Parameters of Resource Block
Function Block Parameters
13 1013 DD_REV 1 — Revision number of the device description (DD)
applied to this FVP110
14 1014 GRANT_
DENY
0 Option to control access from the host
computer and local control panel to tuning and
alarm parameter
15 1015 HARD_
TYPES
Scalar input,
Scalar output
— Bit string indicating the hardware types:
❑ Bit 0: Scalar input
❑ Bit 1: Scalar output
❑ Bit 2: Discrete input
❑ Bit 3: Discrete output
16 1016 RESTART — Restart the FVP110 in the selected way:
1: Running
2: Restart Resource
3: Restart with the default settings defined in
FF
specifications.*1
4: Restart CPU
17 1017 FEATURES — — Shows supportable optional features of the
block.
18 1018 FEATURE_
SEL
— Parameter used to select the optional features
of the resource block
19 1019 CYCLE_
TYPE
Scheduled — Bit string indicating cycle types executable for
the resources
Bit 0: Scheduled; to be scheduled
Bit 1: Event driven; to be driven by an event
Bit 2: Manufacturer specified; executable by a
manufacturer-specified unique function
20 1020 CYCLE_SEL Scheduled Bit string used to select the cycle type
21 1021 MIN_CYCLE_
T
3200 (100ms) — Minimum execution cycle
22 1022 MEMORY_
SIZE
0—
Memory size allowed for use of function
block configurations in the device; checked
before a download, but not supported by
the FVP110.
Table 60 Resource Block Parameters (Continued)
Relative
Index
Index Parameter
Name
Default
(factory
setting)
Write Description
To Next Page
