Parameters of Resource Block
Function Block Parameters
37 1037 ALARM_SUM Enable Shows the alarm summary for all blocks within
the device (FVP110).
38 1038 ACK_
OPTION
0XFFFF Defines the acknowledgment action of each
alarm type.
By setting a bit to 1, the corresponding alarm
will behave as acknowledged immediately
when it occurs without receipt of
acknowledgment from the host.
39 1039 WRITE_PRI 0 Defines the priority level of WRITE_ALM as
well as allows for notification to be disabled
and makes acknowledgment unnecessary for
WRITE_ALM.
40 1040 WRITE_ALM — — Alarm generated when WRITE_LOCK is set to
unlocked
41 1041 ITK_VER 4 — Version number of the inter-operability test kit
42 1042 SOFT_REV — — Revision number of software
43 1043 SOFT_DSC — — Revision number of software for development
purpose.
44 1044 SIM_ENABLE
_MSG
Null — Used to determine whether to enable the
simulation function to run. To enable, set
“REMOTE LOOP TEST SWITCH”.
45 1045 DEVICE_STA
TUS_1
0 — Shows device statuses - mainly link object
setting statuses.
46 1046 DEVICE_STA
TUS_2
0 — Shows device statuses - mainly individual for
each block status.
47 1047 DEVICE_STA
TUS_3
0 — Shows device statuses - mainly the contents of
XD_ERROR in each block.
48 1048 DEVICE_STA
TUS_4
0 — Not used in the FVP110.
49 1049 DEVICE_STA
TUS_5
0 — Not used in the FVP110.
50 1050 DEVICE_STA
TUS_6
0 — Not used in the FVP110.
Table 60 Resource Block Parameters (Continued)
Relative
Index
Index Parameter
Name
Default
(factory
setting)
Write Description
