GE FVP110 - Parameters of IS (SIGSEL) Block

193
Parameters of Transducer Block
Function Block Parameters
54 2054 VALVE_HYS 0 % — Hysteresis of valve actions (%); a parameter
set by auto tuning
55 2055 VALVE_SLIP
_WIDTH
0 % — Slip width of valve actions (%); a parameter set
by auto tuning
56 2056 MEAS_
PRESS_AIR
0 kPa — Air pressure (%); a parameter set by auto
tuning (Valid when an optional pressure sensor
is specified.)
57 2057 MEAS_
PRESS
_SUPPLY
0 kPa — Air supply pressure (%); a parameter set by
auto tuning (Valid when an optional pressure
sensor is specified.)
58 2058 MEAS_
SPRING
_RANGE
0 kPa — Spring range of valve; a parameter set by auto
tuning (Valid when an optional pressure sensor
is specified.)
59 2059 CONTROL_
DIR
2 — Defines the acting direction of the feedback
loop:
1 = direct
2 = reverse
60 2060 THETA_HI(*1)
(*2)
+ 0.2 rad. — Upper angle signal limit of position sensor (in
radians)
61 2061 THETA_LO
(*1)(*2)
-0.2 rad. — Upper angle signal limit of position sensor (in
radians)
62 2062 THETA_P(*1)
(*2)
0 rad. — Angle signal equal to 50 % from position
sensor (in radians)
63 2063 TRAVEL_
CALIB
_EXEC
1 O/S Switch for starting a travel calibration.
64 2064 TRAVEL_
CALIB
_RESULT
1 — Indicates the result of a travel calibration.
65 2065 OPEN_STOP
_ADJ
– — Not used for FVP110.
66 2066 AUTO_TUNE
_EXEC
1 O/S Switch for starting auto tuning.
Table 61 Transducer Block Parameters (Continued)
Relative
Index
Index Parameter
Name
Default
(factory
setting)
Write Description
