Hydran* M2-X Instruction Manual
Page 154
MA-029 Rev. 1.0, 30-Jul-18
Appendix B. Installation Checklist
Read all warnings and recommendations in Chapter 1 before
proceeding with the installation.
This Appendix lists every step of the installation procedure. The numbers on the
left indicate the Section numbers; those on the right indicate the page where this
Section is located.
4.3
Installation
73
4.3.1
Overview
73
1. Mount the sensor on a full-bore gate or ball valve
[ ]
2. The valve’s nominal diameter is 1.5 in or larger
[ ]
3. Mount the Hydran M2-X horizontally
[ ]
4.3.2
Verifying the Serial Numbers
77
1. Ensure the following serial numbers correspond to those indicated on the Test
Certificate and Data Sheet and the shipping box
• Serial number of the sensor (located under the sensor’s connector)
[ ]
• Serial number of the Hydran M2-X (located on the heater plate)
[ ]
4.3.3
Preparing the Valve
79
1. Wipe the outside of the valve
[ ]
2. Clean the valve’s threads
[ ]
3. Dispose of the collected oil according to the company regulations
[ ]
4.3.4
Separating the Sensor from the Hydran M2-X
79
1. Remove the set screw that secures the Hydran M2-X and sensor
[ ]
2. Remove the sensor clamp using the spanner wrench
[ ]
3. Carefully pull the sensor a few centimeters from the enclosure
[ ]
4. Disconnect the connector located at the back of the sensor
[ ]
5. Inspect the membrane inside the sensor by looking at it
[ ]
6. Store all parts in a box until ready for installation
[ ]
WARNING
