Hydran* M2-X Instruction Manual
MA-029 Rev. 1.0, 30-Jul-18
3. Close the Hydran M2-X’s cover; make sure the gasket is properly positioned
between the heater plate and the cover.
4. Store the Hydran M2-X in its shipping box, ready for installation.
Note: For storage information, see Section 4.1.4.
4.3 Installation
All procedures in this manual must be strictly adhered to.
Any deviation from these could cause irreversible damages
to the Hydran M2-X and/or the transformer being monitored,
and could lead to property damage, personal injury and/or
death. Installation and maintenance of the Hydran M2-X
must be carried out by qualified personnel only.
The installation and commissioning of the Hydran M2-X are divided in several
steps. This Section provides a detailed description of each step; Appendix B provides
a checklist for the entire installation procedure.
It is strongly recommended to verify the operation of all
Hydran M2-X’s before installation in the field. The verification
also allows the user to become familiar with the Hydran M2-
X; see Section 4.2.
Note: It is strongly recommended that the parameters of each Hydran M2-X
(identification number, power station identification number, communication
speed, operation mode of relays, etc.) be set before field installation.
4.3.1 Overview
4.3.1.1 Typical Installation
The Hydran M2-X is typically installed on a full-bore gate or ball valve of a
transformer. There are two cables:
• The Hydran M2-X’s power supply cable is passed in a flexible (recommended)
or rigid steel conduit toward a supervisory control and data acquisition
(SCADA) system.
• The alarm cable is passed in a flexible (recommended) or rigid steel conduit
toward a SCADA system.
4.3.1.2 Mounting Locations of the Hydran M2-X on a Transformer
