– The Hydran M2-X Installation Guide.
3. Set of tools and accessories:
• 3/16-in Allen key with 9-in T-shape handle (part number 11817), used for
the four screws of the cover.
• 5/32-in Allen key with short L-shape handle (part number 10013), used for
the sensor’s bleed screw.
• 1/16-in Allen key with short L-shape handle (part number 18048), used for
the sensor clamp set screw.
• Spanner wrench, used for the sensor clamp.
• Roll of Teflon tape (part number 10521).
• 1.8-m (6-ft) RS-232 cable (part number 12309).
4.1.3 Inspection
1. Using the shipping list (see Section 4.1.2), ensure all items are present.
2. Remove the four screws (for location, see Figure 2-3) that maintain the cover
in place, using the long 3/16-in Allen key with a 9-in T-shape handle.
3. Remove the cover.
4. Inspect the cover, sensor and electronic card cage for any visual damage
(bump, scratch or others).
5. Ensure the serial numbers of the following Hydran M2-X’s components
correspond to those indicated on the Test Certificate and Data Sheet (for an
example, see Figure 3-12) and the shipping box:
• Serial number of the sensor (located under the sensor’s connector; see
item 5 in Figure 2-7).
• Serial number of the Hydran M2-X (located on the heater plate).
Note: Each Hydran M2-X is configured for a specific sensor. If several Hydran M2-
X’s are received, take the necessary precautions not to swap the sensors and
Hydran M2-X’s.
6. Ensure the installed I/O options (see item 3 in Figure 2-5) correspond to those
indicated on the Test Certificate and Data Sheet (for an example, see Figure
3-12) and the purchase order.
7. Report any discrepancies to the company supervisor and the General Electric
Customer Service (the coordinates can be found at the bottom of page 9).
Note: Never return equipment without first contacting the General Electric
Customer Service (the coordinates can be found at the bottom of page 9).
