Hydran* M2-X Instruction Manual
MA-029 Rev. 1.0, 30-Jul-18
Never touch the gas detector or humidity sensor inside the
Hydran M2-X sensor. Touching them may damage the
Hydran M2-X.
Figure 4-4: Disconnecting the Sensor Cable
6. Inspect the membrane inside the sensor by looking at it; its surface must be
flat, without cut or tear (a small curl is normal).
7. Store all parts, including the sensor, in a box and in a safe place until ready for
installation.
1. Rotate sensor connector anti-clockwise
(approximately 1/8 turn).
2. Pull connector from sensor.
