DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
3 - 16 Section 3-4 - Completing the setup
Section 3-4
Completing the setup
Contents in this section
3-4-1 Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16
3-4-2 LOGIQ E10 specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16
3-4-3 Electrical specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-17
3-4-4 Connections on the I/O Rear panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-18
3-4-5 Connections on the Patient I/O panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-19
3-4-6 Connecting Probes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-19
3-4-7 Power On/Boot Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-21
3-4-8 Password Policies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-24
3-4-9 Disc Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-28
3-4-10 Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-31
3-4-11 Logoff/Power shut down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-33
3-4-12 Complete power down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-34
3-4-1 Purpose of this section
This section describes how to complete the set up of LOGIQ E10.
3-4-2 LOGIQ E10 specifications
LOGIQ E10 requirements verification
• Verify that the site meets the requirements listed in (see: Section 2-3 "Facility needs" on page 2-9).
• Verify that the specifications below do not conflict with any on-site conditions.
Physical dimensions
The physical dimensions of the LOGIQ E10 are summarized in Table 3-5.
* Dimensions given with floating keyboard stowed for transport and the Main Monitor down.
Mass with monitor and peripherals
Acoustic noise output
Less than 48 dB(A) at 20 degrees Celsius at a distance of 1 meter at all four sides, 1 meter above the
floor.
Table 3-5 Physical dimensions of LOGIQ E10 with monitor and peripherals
HEIGHT* WIDTH DEPTH UNIT
1300 585 990 mm
51 23 39 inches
Table 3-6 Mass with monitor and peripherals
MODEL NUMBER WEIGHT [KG] WEIGHT [LBS]
5935000E10 135 298

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
