GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
1 - 18 Section 1-4 - Safety considerations
Section 1-4
Safety considerations
Contents in this section
1-4-1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-18
1-4-2 Human safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-18
1-4-3 Mechanical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-21
1-4-4 Electrical safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-24
1-4-5 Battery safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-25
1-4-1 Introduction
The following safety precautions must be observed during all phases of operation, service, and repair
of this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this
manual violates safety standards of design, manufacture, and intended use of the equipment.
1-4-2 Human safety
• Operating personnel must not remove the Ultrasound system covers.
• Servicing should be performed by authorized personnel only.
Only personnel who have participated in a LOGIQ E10 Training Seminar are authorized to service the
equipment.
DANGER
DANGEROUS VOLTAGES, CAPABLE OF CAUSING DEATH, ARE PRESENT IN
THIS EQUIPMENT. USE EXTREME CAUTION WHEN HANDLING, TESTING AND
ADJUSTING.
DANGER
WITH THE POWER ASSISTANT OPTION, DANGEROUS VOLTAGES, CAPABLE
OF CAUSING DEATH, ARE PRESENT IN THIS EQUIPMENT. DO NOT REMOVE
THE CAPACITOR PACK COVER.
WARNINGWARNING
IF THE COVERS ARE REMOVED FROM AN OPERATING LOGIQ E10, SOME METAL
SURFACES MAY BE WARM ENOUGH TO POSE A POTENTIAL HEAT HAZARD IF
TOUCHED, EVEN WHILE IN SHUTDOWN MODE.
WARNINGWARNING
BECAUSE OF THE LIMITED ACCESS TO CABINETS AND EQUIPMENT IN THE FIELD,
PLACING PEOPLE IN AWKWARD POSITIONS, GE HAS LIMITED THE LIFTING WEIGHT
FOR ONE PERSON IN THE FIELD TO 16 KG (35 LBS). ANYTHING OVER 16 KG (35 LBS)
REQUIRES 2 PEOPLE.
CAUTION
HAVE TWO PEOPLE AVAILABLE TO DELIVER AND UNPACK THE LOGIQ E10.
ATTEMPTS TO MOVE THE LOGIQ E10 CONSIDERABLE DISTANCES OR ON AN INCLINE
BY ONE PERSON COULD RESULT IN INJURY OR DAMAGE OR BOTH.

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
