GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
1 - 10 Section 1-3 - Important conventions
1-3-3 Product icons
The following table describes the purpose and location of safety labels and other important information
provided on the LOGIQ E10.
NOTE: This machine should be used in compliance with law. Some jurisdictions restrict certain uses,
such as gender determination (shown for country specific label).
Figure 1-1 Rear Panel Label Location
Table 1-5 Label Icons (Rear of Console)
Item Label/Icon Purpose/Meaning
1. GE Cares Label (US/Canada systems only)
