GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 228 Section 8-10 - Casters and Brakes replacement
Section 8-10
Casters and Brakes replacement
8-10-1 Purpose of this section
This section describes how to replace the replaceable parts for the Casters and Brakes.
Contents in this section
8-10-1 Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-228
8-10-2 Rear Caster(s) replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-229
8-10-3 Front Caster(s) replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-232
8-10-4 Caster Hubcap replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-236
8-10-5 Pedal Mechanism replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-239
8-10-6 Pedal Mechanism Cam FRU replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-244
8-10-7 Pedal Mechanism Covers replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-250

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
