GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 236 Section 8-10 - Casters and Brakes replacement
8-10-4 Caster Hubcap replacement
Table 8-258 Manpower / Time and Tool
Manpower /
Time
Tools / PPE
One person /
5 minutes
Refer to: 8-2-5 "Tools needed for servicing the LOGIQ E10" on page 8-6 /
8-2-6 "PPE Required During Service" on page 8-6.
Table 8-259 Preparations and Preparation Links
Preparations - you must perform the following steps
WARNINGWARNING
OR
Make sure to wear safety glasses or safety goggles for personal protection, as the hubcap
may splinter and/or shatter during removal.
1. Power down the system.
2. Disconnect the mains power cable from the wall outlet.
