DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 270 Section 8-11 - Front End Acquisition / Card Cage parts replacement
CRX removal
Table 8-297 CRX removal
Step Corresponding Graphic
CRX Board location
1.
Using the board ejector levers, remove the CRX Board. Place on an ESD safe place.
