DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 386 Section 8-14 - Cables replacement
8-14-2 Main Cable replacement
Manpower
One person, 30 minutes.
Tools / PPE
For tools needed, refer to: 8-2-5 "Tools needed for servicing the LOGIQ E10" on page 8-6 /
8-2-6 "PPE Required During Service" on page 8-6.
Preparations
When preparing for the replacement, you must perform the following steps:
1.) Power down the system.
2.) Disconnect the mains power cable from the wall outlet and all Probes and External I/O Cabling.
3.) Remove six OP Knobs.
4.) Remove the Upper OP, Lower OP, the Left Side Cover, the Top Cover and the Main Cable Cover.
For more information:
•
4-2-4 "Power SHUT DOWN" on page 4-9.
• 8-7-9 "Upper OP (Operator Panel)/Touch Panel Assembly replacement" on page 8-117.
• 8-7-10 "Lower OP (Operator Panel) replacement" on page 8-122.
• 8-6-16 "Main Cable Cover replacement" on page 8-73.
To Next Page
