GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
9 - 6 Section 9-6 - Covers and Bumpers
5.
Handle Rear 5738012 1 Y
6.
Left Support Assembly Frey 5307245 1 Y
7.
Right Support Asm Frey 5307243 1 Y
8.
LOGIQ E10 Main Diplay Bezel Label 5789927 1 Y
9.
Cover Rear - OLED monitor with label GC307351 1 Y
10.
GE Logo Badge 100MM - Onyx Black 5446869-2 2 Y
Table 9-5 Covers and Bumpers - LOGIQ E10 2 of 6
ITEM PART NAME PART NUMBER DESCRIPTION QTY FRU
LOGIQ E10
