10 - 10 Section 10-5 - Tools Required
10-5-4 Peripheral/option checks
If any peripherals or options are not part of the system configuration, the check can be omitted.
10-5-5 Mains cable inspection
10-5-6 Optional diagnostic checks
To complete the Ultrasound System checks, view the error logs and run desired diagnostics.
10-5-7 View the logs
1.) Review the Ultrasound system error log for any problems.
2.) Check the temperature log to see if there are any trends that could cause problems in the future.
Table 10-6 GE approved peripheral/hardware option functional checks
Step Item Description
1 Media
Verify media drive(s) read/write properly. Clean if necessary.
2 B/W Printer
Verify hardcopy output of the B/W video page printer. Clean heads and covers if necessary.
3 Color Printer
Verify hardcopy output of the Color video page printer. Clean heads and covers if necessary.
4DICOM
Verify that DICOM is functioning properly. Send an image to a DICOM device.
5ECG
Verify basic operation with customer
6 Footswitch
Verify that the footswitch is functioning as programed. Clean as necessary.
Table 10-7 Mains Cable Inspection, As Appropriate
Step Item Description
1 Unplug cord
Disconnect the mains cable from the wall and Ultrasound system.
2 Inspect
Inspect it and its connectors for damage of any kinds.
3Verify
Verify that the LINE, NEUTRAL and GROUND wires are properly attached to the terminals, and that
no strands may cause a short circuit.
4Verify
Inlet connector retainer is functional.
