2 - 14 Section 2-3 - Facility needs
DICOM option setup requirements (cont’d)
Figure 2-3 Worksheet for DICOM Network Information
LOGIQ
E10
Host Name
AE Title
Local Port
IP Address
Net Mask
...
...
...
Default Gateway
DICOM APPLICATION
NAME
Store 2
Store 3
Store 1
MAKE/ IP PORTAE TITLE
DICOM
Print
Storage
Commit
DICOM
MPPS
Worklist
...
...
...
...
...
...
...
Network
Speed
Associated
Storage AE
_____________
__Raw Data
__Allow Multiframe
__Structured
Reporting
Compression_______
__Raw Data
__Allow Multiframe
__Structured
Reporting
Compression_______
__Raw Data
__Allow Multiframe
__Structured
Reporting
Compression_______
Vendor: ___________
Print Size: _________
Medium: ___________
Copies: ___________
Orientation: ________
Color ______________
OTHER
CONFIGURATION
DHCP

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
