9-4 MAC™ 1600 2028451-182B
System Configuration
Page 2
Power up mode Determines which screen will appear when the device is
powered on. Available options are:
Resting ECG
Arrhythmia
Main Menu
Stress ECG
Resting ECG is the default value. Stress ECG are
available only if the ERGO option has been activated. For
more information, refer to “Options Setup” on page 9-29.
Display Colors Determines the appearance the ECG display. Select a
color combination that is legible for you.
ECG Grid on Display Determines whether a grid is displayed behind the
waveforms. A grid may make reading the ECG easier.
Default is on.
Anti-Aliasing of ECG
Waveforms
Determines whether anti-aliasing will be applied to
waveforms to reduce distortion caused by the video
display. Default is on.
Power for External Modem Determines whether power should be provided to an
external modem through the serial cable. If enabled, the
MAC 1600 system will provide power when the modem
transmits or receives data and disconnect the power when
the communication completes.
Enable this option only if you use the GE supplied cable
and an external GE modem that has been modified to
obtain its power through the serial cable. Enabling this
option when using a standard cable or modem may cause
communication issues.
Auto Standby Determines whether the device will automatically enter
standby mode if it is inactive for a predefined time limit.
This helps reduce power consumption and increases the
life of the device. See also Auto Standby Time.
Auto Standby Time
(1-255 min)
Identifies the amount of time, in minutes, that the device
can remain inactive before it enters standby mode. Used
by the Auto Standby field.
Stress Test Identifies the device used to perform the stress test.
Available only if the ERGO option is enabled.
For information on enabling stress tests, refer to “Stress
ECG Settings” on page 9-13.
For information on conducting stress tests, see Chapter 7.
Field Comment
To Next Page
