GE Series 90-30 PLC - Page 165

GFK-0356Q Chapter 7 Input/Output Modules 7-5
7
Pin A12
Pin A1
A1 2 3 4 5 6 7 8
B1 2 3 4 5 6 7 8
F
C1 2 3 4 5 6 7 8
D1 2 3 4 5 6 7 8
CD
AB
INPUT
5/12 VDC
POS/NEG LOGIC
3.0 mA/Pt at 5VDC
8.5 mA/Pt at 12VDC
Right Side
Connector
Left Side
Connector
LED Indicators
Pin B12
Pin A12
Pin B1
Pin A1
Figure 7-2. Example of 32-Point I/O Module (IC693MDL654) With Dual Connectors
7.5 mA/Pt
INPUT 32 PT
24 VDC ISOL
NEG/POS LOGIC
Connector Pin
Numbering
50
19
18
32
33
1
Figure 7-3. Example of 32-Point I/O Module (IC693MDL653) With Single Connector
