12-14 Series 90-30 PLC Installation and Hardware Manual

–

August 2002 GFK-0356Q

Catalog

Number Description +5 VDC

+24 VDC Relay

Power

+24 VDC

Isolated

IC693MDL643 24 VDC Positive Logic, FAST, 16 Point Input 5 – 120

IC693MDL644 24 VDC Negative Logic, FAST, 16 Point Input 5 – 120

IC693MDL645 24 VDC Pos/Neg Logic, 16 Point Input 80 – 125

IC693MDL646 24 VDC Pos/Neg Logic, FAST, 16 Point Input 80 – 125

IC693MDL652 24 VDC Pos/Neg Logic 32 Point Input 5 – –

IC693MDL653 24 VDC Pos/Neg Logic, FAST, 32 Point Input 5 – –

IC693MDL654 5/12 VDC (TTL) Pos/Neg Logic, 32 Point

195/440

––

IC693MDL655 24 VDC Pos/Neg, 32 Point Input 195 – 224

IC693MDL730 12/24 VDC Positive Logic, 2A, 8 Point Output 55 – –

IC693MDL731 12/24 VDC Negative Logic, 2A, 8 Point Output 55 – –

IC693MDL732 12/24 VDC Positive Logic, 0.5A, 8 Point Output 50 – –

IC693MDL733 12/24 VDC Negative Logic, 0.5A, 8 Point Output 50 – –

IC693MDL734 125 VDC Pos/Neg Logic, 6 Point Output 90 – –

IC693MDL740 12/24 VDC Positive Logic, 0.5A, 16 Point Output 110 – –

IC693MDL741 12/24 VDC Negative Logic, 0.5A, 16 Point Output 110 – –

IC693MDL742 12/24 VDC Pos. Logic ESCP, 1A, 16 Point Output 130 – –

IC693MDL750 12/24 VDC Negative Logic, 32 Point Output 21 – –

IC693MDL751 12/24 VDC Positive Logic, 32 Point Output 21 – –

IC693MDL752 5/24 VDC (TTL) Negative Logic, 0.5A, 32 Point 260 – –

IC693MDL753 12/24 VDC Positive Logic, 0.5A, 32 Point Output 260 – –

IC693MDL930 Relay, N.O., 4A Isolated, 8 Point Output 6 70 –

IC693MDL931 Relay, N.C. and Form C, 8A Isolated, 8 Point Out 6 110 –

IC693MDL940 Relay, N.O., 2A, 16 Point Output 7 135 –

IC693MDR390 24 VDC Input, Relay Output, 8 In/8 Out 80 70 –

IC693PCM300 Programmable Coprocessor Module, 65K 425 – –

IC693PCM301 Programmable Coprocessor Module, 85K 425 – –

IC693PCM311 Programmable Coprocessor Module, 380K 400 – –

IC693PRG300 Hand-Held Programmer 170 – –

IC693PTM100 Power Transducer Module 400

IC693TCM302 Temperature Control Module 150 – –

Refer to module specifications in GFK-0898, Series 90-30 I/O Module Specifications Manual for more details.

** Note that the model 350-364 CPUs do not support the A version (IC690ACC901A) of the Miniconverter.

Power Supply Loading Calculation Examples

Following are examples of calculations for determining the total load placed on a Series 90-30 PLC

power supply by the Series 90-30 PLC hardware. All current figures are expressed in milliamps.

Note that although each output is rated at 15 or 20 watts (with the exception that the +5 VDC

output for the High Capacity power supply is rated at 30 watts), the total combined output can be

no more than 30 watts. The power required by external circuits connected to the 24 VDC

OUTPUT terminals on the power supply terminal strip should be added to the calculation.
