10-64 Series 90-30 PLC Installation and Hardware Manual – August 2002 GFK-0356Q
10
Applications
These cables connect from Series 90-30 I/O modules that use the Fujitsu 24-pin I/O connector to
Terminal Block Quick Connect (TBQC) blocks. There are two categories of these modules:
 32 point modules with two 24-pin connectors: IC693MDL654, IC693MDL655,
IC693MDL752, and IC693MDL753. The IC693CBL329/331/333 cables are for the modules’
left side connector (front view), and the IC693CBL330/332/334 cables are for the modules’
right side connector. The modules’ right side connector interfaces with I/O circuit groups A
and B; the modules’ left side connector interfaces with groups C and D. The other end of the
cables connect to the TBQC IC693ACC337 terminal block. See GFK-0898, the Series 90-30
PLC I/O Module Specifications Manual, for details about these modules. See Appendix H for
information on the TBQC components.
 16-point modules that are equipped with the TBQC I/O faceplate adapter. Use the
IC693CBL330/332/334 right side cables for this application. See Appendix H for information
on the TBQC (Terminal Block Quick Connector) components.

GE Series 90-30 PLC Specifications

General

Series	90-30
Type	Programmable Logic Controller (PLC)
Relative Humidity	5% to 95% non-condensing
Manufacturer	GE Fanuc (now part of Emerson)
Memory	Varies by CPU model
Power Supply	Various options (e.g., 120/240V AC, 24V DC)
I/O Modules	Digital, Analog, Specialty modules
I/O Capacity	Up to 512 I/O points
Communication Ports	RS-232, RS-485, Ethernet
Programming Software	Proficy Machine Edition
Programming Languages	Ladder Logic, Instruction List
Operating Temperature	0°C to 60°C (32°F to 140°F)
Certifications	UL, CE
