State Logic CPU Firmware and PROM Configurations
State Logic CPU Firmware and PROM Table
CPU
Firmware
(standard)
EPROM
(for user
memory)
EEPROM
(for user
memory)
Flash
(for user
memory)
CSE311
EPROM
Optional
N/A
N/A
CSE313
EPROM Optional
N/A
N/A
CSE323
EPROM Optional
N/A
N/A
CSE331
EPROM Optional
N/A
N/A
CSE340
EPROM N/A
N/A
Optional
State Logic CPU Data Sheets
This section provides data sheets describing each of the Series 90-30 State Logic CPU modules.
Each CPU is described in a one-page data sheet, which provides a quick reference to all of the
available CPU models.
■ IC693CSE311 State Logic, 5-slot baseplate with embedded CPU
■ IC693CSE313 State Logic, 5-slot baseplate with embedded CPU
■ IC693CSE323 State Logic, 10-slot baseplate with embedded CPU
■ IC693CSE331 State Logic, CPU module, 10 MHz
■ IC693CSE340 State Logic, CPU module, 20 MHz

GE Series 90-30 PLC Specifications

General

Series	90-30
Type	Programmable Logic Controller (PLC)
Relative Humidity	5% to 95% non-condensing
Manufacturer	GE Fanuc (now part of Emerson)
Memory	Varies by CPU model
Power Supply	Various options (e.g., 120/240V AC, 24V DC)
I/O Modules	Digital, Analog, Specialty modules
I/O Capacity	Up to 512 I/O points
Communication Ports	RS-232, RS-485, Ethernet
Programming Software	Proficy Machine Edition
Programming Languages	Ladder Logic, Instruction List
Operating Temperature	0°C to 60°C (32°F to 140°F)
Certifications	UL, CE
