GE Series 90-30 PLC

GFK-0356Q 4-1
Power Supplies
Power Supply Categories
Series 90-30 power supplies are modular types that plug into the left slot of all 90-30 baseplates.
They have been placed into two categories for the purpose of this chapter:
AC/DC Input Power Supplies
■ IC693PWR321, Standard 120/240 VAC or 125 VDC input, 30 watts total output
■ IC693PWR330, High Capacity 120/240 VAC or 125 VDC input, 30 watts total output
DC Input-Only Power Supplies
■ IC693PWR322, 24/48 VDC input, 30 watts total output
■ IC693PWR328 48 VDC input, 30 watts total output
■ IC693PWR331, High Capacity 24 VDC input, 30 watts total output
Power Supply Feature Comparison
The following table lists the features of the Series 90-30 PLC Power Supplies.
Table 4-1. Power Supply Comparison
Catalog
Number
Load
Capacity
Nominal
Input Output Capacities (Voltage/Power *)
IC693PWR321 30 Watts 100 to 240 VAC or
125 VDC
+5 VDC
15 watts
+24 VDC Isolated
20 watts
+24 VDC Relay
15 watts
IC693PWR330 30 Watts 100 to 240 VAC or
125 VDC
+5 VDC
30 watts
+24 VDC Isolated
20 watts
+24 VDC Relay
15 watts
IC693PWR322 30 Watts 24 or 48 VDC +5 VDC
15 watts
+24 VDC Isolated
20 watts
+24 VDC Relay
15 watts
IC693PWR328 30 Watts 48 VDC +5 VDC
15 watts
+24 VDC Isolated
20 watts
+24 VDC Relay
15 watts
IC693PWR331 30 Watts 24 VDC +5 VDC
30 watts
+24 VDC Isolated
20 watts
+24 VDC Relay
15 watts
*
Total of all outputs combined cannot exceed 30 watts.
4
Chapter
