10-32 Series 90-30 PLC Installation and Hardware Manual – August 2002 GFK-0356Q
10
C
P
U
CPU BASEPLATE
EXPANSION BASEPLATE
REMOTE BASEPLATE
REMOTE BASEPLATE
IC693CHS392/398
EXPANSION
BASEPLATE
MAXIMUM DISTANCE
FROM CPU 50 FEET
(15 METERS)
IC693CHS391/397
CPU
BASEPLATE
IC693CHS393/399
REMOTE
BASEPLATE
REMOTE BASEPLATE
IC693CHS393/399
REMOTE
BASEPLATE
MAXIMUM DISTANCE
FROM CPU= 700 FEET
(213 METERS)
IC693CHS393/399
REMOTE
BASEPLATE
1
2
3
2
3
2
3
4
1
2
3
4
Standard Wye Cable
Custom Built Point-to-Point Cable
IC693CBL300 Standard Wye Cable, Used as Wye Jumper
IC693ACC307 Bus Terminator
Figure 10-22. Example of Connecting Expansion and Remote Baseplates
