10-50 Series 90-30 PLC Installation and Hardware Manual – August 2002 GFK-0356Q
10
Table 10-8. Catalog Numbers for 24-Pin Connector Kits
GE Fanuc
Catalog Number
Vendor
Catalog Number Description
IC693ACC316 FCN-361J024-AU Solder eyelet receptacle
(Solder Eyelet Type) FCN-360C024-B Backshell (for above)
IC693ACC317 FCN-363J024 Crimp wire receptacle
(Crimp Type) FCN-363J-AU Crimp pin (for above, 24 needed)
FCN-360C024-B Backshell (for above)
IC693ACC318 FCN-367J024-AUF IDC (ribbon) receptacle, closed cover
(Ribbon or IDC Type) FCN-367J024-AUH IDC (ribbon) receptacle, open cover
Additional tools from Fujitsu are required to properly assemble the crimped contact and ribbon
cable type connectors. The solder eyelet connectors (as provided in IC693ACC316) do not require
any special tooling.
Crimped Contact Connectors (as provided in IC693ACC317) require :
Hand Crimping Tool FCN-363T-T005/H
Contact Extraction Tool FCN-360T-T001/H
Ribbon Cable Connectors (as provided in IC693ACC318) require :
Cable Cutter FCN-707T-T001/H
Hand Press FCN-707T-T101/H
Locator Plate FCN-367T-T012/H
These tools need to be ordered from an authorized Fujitsu distributor. Three of the largest US
distributors for Fujitsu connectors are Marshall at (800)522-0084, Milgray at (800)MILGRAY, and
Vantage at (800)843-0707. If none of these distributors service your area, then contact Fujitsu
Microelectronics in San Jose, California, USA via telephone at (408) 922-9000 or via fax at (408)
954-0616 for further information.
It is recommended that you order any necessary connector tooling with sufficient lead time to meet
your assembly requirements for these connectors. These tools are generally not stock items and
can have significant lead times from distribution. If you have any further questions about this
issue, please feel free to contact the GE Fanuc PLC Technical Support Hotline at 1-800-GE
FANUC (1-800-433-2682), or International dial direct 804-978-6036.
Pin connections with color codes are shown in the following table. Cables are made of 12 twisted
pairs; wire size is
#24 AWG (0.22mm
2
).
