Chapter 8 - Replacement Procedures 8-143
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
8-7-7-5 PCIe Cable Installation Procedure
1.) Connect the new PCIe cable to the BIB board and to the BE module.
2.) Install the BE module.
3.) Refit the following covers: Lower Front eTower, Left side eTower, and Right Side eTower,
4.) Install all accessories.
5.) Turn ON power to the system.
• BE Module Installation Procedure
• Right Side eTower Cover Installation Procedure
• Left Side eTower Cover Installation Procedure
• Lower Front eTower Cover Installation Procedure
• Accessories - Replacement Procedures
Perform the checks listed in PCIe Cable Replacement Procedure on page 8-218
