SUSPENDED WORKING PLATFORM AB 450 / 650 Technical data
BL061 GB Edition 04/2016
29 / 96 Assembly and operating manual
Operation with front suspension
Length of
BMU
platform
Total weight of
the suspended
structure –
Load capacity of
the platform
Load capacity
with persons
2 m 240 kg 400 kg 240 kg + 2
b
3 m 255 kg 600 kg
440 kg + 2b
360 kg + 3
b
280 kg + 4b
4 m 290 kg 605 kg
445 kg + 2
b
365 kg + 3
b
285 kg + 4b
5 m 305 kg 590 kg
430 kg + 2b
350 kg + 3
b
270 kg + 4b
6 m 320 kg 575 kg
415 kg + 2b
335 kg + 3
b
255 kg + 4b
7 m 345 kg 550 kg
390 kg + 2
b
310 kg + 3
b
230 kg + 4b
8 m 370 kg 525 kg
365 kg + 2
b
285 kg + 3
b
205 kg + 4b
9 m 385 kg 510 kg
350 kg + 2
b
270 kg + 3
b
190 kg + 4
b
10 m 410 kg 485 kg
325 kg + 2
b
245 kg + 3
b
165 kg + 4
b
11m 435 kg 460 kg
300 kg + 2
b
220 kg + 3
b
140 kg + 4
b
12 m 450 kg 445 kg
285 kg + 2
b
205 kg + 3
b
125 kg + 4
b
13 m 475 kg 420 kg
260 kg + 2
b
180 kg + 3
b
100 kg + 4
b
14 m 500 kg 400 kg
240 kg + 2
b
160 kg + 3
b
80 kg + 4
b
Specifications for operating height of 100 m
