SUSPENDED WORKING PLATFORM AB 450 / 650 Technical data
BL061 GB Edition 04/2016
31 / 96 Assembly and operating manual
3.6.4 Suspended working platform with 2 x GEDA AB 650
Operation with C-clamp
Length of
BMU
platform
Total weight of
the suspended
structure –
Load capacity of
the platform
Load capacity
with persons
2 m 321 kg 400 kg 240 kg + 2
b
3 m 340 kg 600 kg
440 kg + 2
b
320 kg + 3
b
240 kg + 4b
4 m 371 kg 800 kg
640 kg + 2b
560 kg + 3
b
480 kg + 4b
5 m 386 kg 910 kg
750 kg + 2b
670 kg + 3
b
590 kg + 4
b
6 m 400 kg 895 kg
735 kg + 2
b
655 kg + 3
b
575 kg + 4b
7 m 426 kg 870 kg
710 kg + 2b
630 kg + 3
b
550 kg + 4b
8 m 451 kg 845 kg
685 kg + 2
b
605 kg + 3
b
525 kg + 4b
9 m 466 kg 830 kg
670 kg + 2
b
590 kg + 3
b
510 kg + 4
b
10 m 491 kg 805 kg
645 kg + 2b
565 kg + 3
b
485 kg + 4b
11m 516 kg 780 kg
620 kg + 2
b
540 kg + 3
b
460 kg + 4
b
12 m 531 kg 765 kg
605 kg + 2b
525 kg + 3
b
445 kg + 4b
13 m 556 kg 740 kg
580 kg + 2
b
500 kg + 3
b
420 kg + 4b
14 m 581 kg 715 kg
555 kg + 2b
475 kg + 3
b
395 kg + 4b
Specifications for operating height of 100 m
