GEDA AB 650 - Mounting the Parapet Bracket

GEDA
®
SUSPENDED WORKING PLATFORM AB 450 / 650 Assembly
BL061 GB Edition 04/2016
45 / 96 Assembly and operating manual
5.2 Mounting the parapet bracket
¾ Place parapet bracket (1) over the parapet.
¾ Push counter bearing (2) against the inner side of the parapet and
pin.
1
2
