GEDA AB 650 - Mounting the End Protection; Mounting the Chassis (Optional); Mounting the Spacers (Optional)

Assembly GEDA
®
SUSPENDED WORKING PLATFORM AB 450 / 650
Assembly and Operating Manual
48 / 96 BL061 GB Edition 04/2016
5.3.3 Mounting the end protection
¾ Mount the end protection to both sides.
5.3.4 Mounting the chassis (optional)
¾ Mount the chassis (5) on the
outer cross-member.
5.3.5 Mounting the spacers (optional)
¾ Hook the spacers (6) to the toe
board on the façade side of the
platform and secure with the
clamping screw (6A).
)
The spacers can be moved laterally.
5
6A
6
