Operation GEDA
®
SUSPENDED WORKING PLATFORM AB 450 / 650
Assembly and Operating Manual
64 / 96 BL061 GB Edition 04/2016
6.3 Operation / Function
Control is carried out using the single/central control box from the
working platform.
The ascend is limited by the limit switch approach plate.
Descending is not limited by a limit switch.
Operation with two or three rope winches
When operating the working platform, slippage of the rope winch or
differences in the rotational speed result in an increase in the tilt of the
working platform. This inclination > 4° is balanced out automatically by
the central control box. It is also possible to balance out the inclination
manually.
