Technical data GEDA
®
SUSPENDED WORKING PLATFORM AB 450 / 650
Assembly and Operating Manual
32 / 96 BL061 GB Edition 04/2016
Operation with front suspension
Length of
BMU
platform
Total weight of
the suspended
structure –
Load capacity of
the platform
Load capacity
with persons
2 m 240 kg 400 kg 240 kg + 2
b
3 m 255 kg 600 kg
440 kg + 2b
320 kg + 3
b
240 kg + 4b
4 m 290 kg 800 kg
640 kg + 2
b
560 kg + 3
b
480 kg + 4b
5 m 305 kg 990 kg
830 kg + 2b
750 kg + 3
b
670 kg + 4b
6 m 320 kg 975 kg
815 kg + 2b
735 kg + 3
b
655 kg + 4b
7 m 345 kg 950 kg
790 kg + 2
b
710 kg + 3
b
630 kg + 4b
8 m 370 kg 925 kg
765 kg + 2
b
685 kg + 3
b
605 kg + 4b
9 m 385 kg 910 kg
750 kg + 2
b
670 kg + 3
b
590 kg + 4
b
10 m 410 kg 885 kg
725 kg + 2b
645 kg + 3
b
565 kg + 4b
11m 435 kg 860 kg
700 kg + 2
b
620 kg + 3
b
540 kg + 4
b
12 m 450 kg 845 kg
685 kg + 2b
605 kg + 3
b
525 kg + 4b
13 m 475 kg 820 kg
660 kg + 2
b
580 kg + 3
b
500 kg + 4b
14 m 500 kg 795 kg
635 kg + 2
b
555 kg + 3
b
475 kg + 4b
Specifications for operating height of 100 m
