gefran SIEIDrive ADV100 User Manual

120 ADV100 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.43 4670 Optionbusactivity ENUM Disable 0 4 ERW FVS
Setting of the behaviour of the drive in case of an OptBusFault alarm.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.44 4680 GroundFaultthr perc FLOAT 10.0 0 150.0 ERWS FVS
Setting of the threshold for the ground short circuit alarm GroundFault.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.45 4700 Alarmdigsel1 ENUM No alarm 0 40 ERW FVS
24.46 4702 Alarmdigsel2 ENUM No alarm 0 40 ERW FVS
24.47 4704 Alarmdigsel3 ENUM No alarm 0 40 ERW FVS
24.48 4706 Alarmdigsel4 ENUM No alarm 0 40 ERW FVS
Setting of the alarm signal to enable on a digital output. The digital output is selected using parameters Almdigout
mon1÷4, which can be enabled in the L_DIGSEL1 selection list.
0 No alarm
1 Overvoltage
2 Undervoltage
3 Ground fault
4 Overcurrent
5 Desaturation
6 MultiUndervolt
7 MultiOvercurr
8 MultiDesat
9 Heatsink OT
10 HeatsinkS OTUT
11 Intakeair OT
12 Motor OT
13 Drive overload
14 Motor overload
15 Bres overload
16 Phaseloss
17 Opt Bus fault
18 Opt 1 IO fault
19 Opt 2 IO fault
20 Opt Enc fault
21 External fault
22 Speed fbk loss
23 Overspeed
24 Speed ref loss
25 Emg stop alarm
26 Power down
27 Not Used1
28 Not Used2
29 Not Used3
30 Not Used4
31 Not Used5
32 Not Used6
33 Plc1 fault
