Read Operation
4 pages (16 bytes) are read at the same time.
To perform a read operation, use the standard PC/SC “Read Binary” command:
ABLL 16 bytes read
00h Page 0 + Page 1 + Page 2 + Page 3
01h Page 1 + Page 2 + Page 3 + Page 4
02h Page 2 + Page 3 + Page 4 + Page 5
03h Page 3 + Page 4 + Page 5 + Page 6
04h Page 4 + Page 5 + Page 6 + Page 7
05h Page 5 + Page 6 + Page 7 + Page 8
06h Page 6 + Page 7 + Page 8 + Page 9
07h Page 7 + Page 8 + Page 9 + Page 10
08h Page 8 + Page 9 + Page 10 + Page 11
09h Page 9 + Page 10 + Page 11 + Page 12
0Ah Page 10 + Page 11 + Page 12 + Page 13
0Bh Page 11 + Page 12 + Page 13 + Page 14
0Ch Page 12 + Page 13 + Page 14 + Page 15
0Dh Page 13 + Page 14 + Page 15 + Page 0
0Eh Page 14 + Page 15 + Page 0 + Page 1
0Fh Page 15 + Page 0 + Page 1 + Page 2
Other An error 94h 0Fh will be returned
As an example the response will be:
• For ABLL = 00h:
SN0 SN1 SN2 BCC0 SN3 SN4 SN5 SN6 BCC1 Internal Lock0 Lock1 OTP0 OTP1
OTP2 OTP3 90h 00h
• For ABLL = 04h:
Data0 Data1 Data2 Data3 Data4 Data5 Data6 Data7 Data8 Data9 Data10 Data11
Data12 Data13 Data14 Data15 90h 00h
• For ABLL = 08h:
Data16 Data17 Data18 Data19 Data20 Data21 Data22 Data23 Data24 Data25
Data26 Data27 Data28 Data29 Data30 Data31 90h 00h
• For ABLL = 0Ch:
Data32 Data33 Data34 Data35 Data36 Data37 Data38 Data39 Data40 Data41
