Reference Manual Preliminary
Prox–DU & Prox–SU
www.gemalto.com Release for first samples Do not use for final design
DOC118569A Public Use Page 34/134
0 x x x x x x x
Different bit rate for both direction is
allowed (do not used this setting)
Note: The list of bit rate reader to card (b2-b0) and card to reader (b6-b4) must be the same.
T=CL card presence check behavior
This byte is used only for test purpose:
00h: the first APDU command to check a T=CL card present is send (normal
behavior)
01h: the first APDU command to check a T=CL card present is not used
Note: the first APDU command has the following format: 00h A4h 00h 00h 00h
Miscellaneous parameters
These bytes are reserved for test purpose. Do not modify them.
General parameters
RF Reset time
This byte defines the time while the RF field is turn off for a RF reset:
00h : default value is used
01h to FFh : time = 5 to 1275 ms (unit = 5 ms)
RF On Delay
This byte defines the delay for the first card command after the RF field is turn on:
00h : default value is used
01h to FFh : time = 5 to 1275 ms (unit = 5 ms)
RF Parameters Usage
This byte defines the usage of the RF Parameters for ISO14443-A and ISO14443-B:
00h: default values are used
01h: user defined values in RF parameters for type A and Type B card are used.
(RxThreshold, RFCfg, TypeB)
Note: The user defined values must be used only for tuning purpose.
RF Power Attenuation
The byte defines the RF power Attenuation or the user defined values for the antenna
output driver conductance:
00h: 0 dB
01h: -1 dB
02h: -2 dB
03h: -3 dB
0Fh: user defined values for the antenna output driver conductance are used.
(GsN, CWGsP and ModGsP)
Note: The user defined values must be used only for tuning purpose.
RF parameters for ISO14443-A cards
