Gemalto Prox-SU User Manual

Reference Manual Preliminary
Prox–DU & Prox–SU
www.gemalto.com Release for first samples Do not use for final design
DOC118569A Public Use Page 18/134
The Prox–DU and a contact smart card:
Figure 10 – The contact smart card is fully inserted into the Prox–DU slot
The Prox–SU and a contactless smart card:
Figure 11 – The contactless smart card is put near or over the Prox–SU landing zone
The Prox–SU and a contact SIM/SAM card:
Figure 12 – The contact SIM/SAM card is inserted into the Prox–SU connector
Note: the SIM/SAM card cannot be installed or removed without opening the casing. The
SIM/SAM card is permanently installed into the Prox–SU reader.
The operating
distance is a few
centimeters
