Reference Manual Preliminary
Prox–DU & Prox–SU
www.gemalto.com Release for first samples Do not use for final design
DOC118569A Public Use Page 88/134
b3-b0 = CWI value 0-F valid
14 bCLockStop 1 00h- 03h ICC clock stop support
00h = Stopping the clock is not
allowed
15 bIfsc 1 01-FEh Size of negotiated IFSC
16 bNadValue 1 NAD value used by CCID
The default values are the following:
bmFindexDindex : 11h
bmTCCKST1 : 10h
bGuardTimeT1 : 00h
bWaitingIntegersT1 : 4Dh
bCLockStop : 00h
bIfsc : 20h
bNadValue : 00h
RDR_to_PC_Escape Command
This message is the response to the PC_to_RDR_Escape command.
Offset Field Size Value Description
0 bMessageType 1 83h RDR_to_PC_Escape
1 bwLength 4 Size of the abData field
5 bSlot 1 00h Slot number : Same as Bulk-Out
message
6 bSeq 1 00-FFh Sequence number : Same as Bulk-
Out message
7 bStatus 1 00h, 01h,
02h, 40h,
41h, 42h
Slot status register:
0Xh = no error
4Xh = command failed
X = 0 card present and active
X = 1 card present and inactive
X = 2 card not present
8 bError 1 00h-FFh Slot error register:
Error when bStatus = 4Xh
9 bRFU 1 00h Reserved for Future Used
10 abData Byte
array
Data sent from CCID
Reporting slot error and slot status registers in bulk-in
messages for the contactless interface
Each bulk-in message contains the values of the Slot Error register (bError) and the Slot
Status register (bStatus).
Theses values are the same as defined in the “Reporting slot error and slot status registers
in bulk-in messages for the contact interface” paragraph.
Interrupt in messages for the contactless card interface
The Interrupt-In endpoint is used to notify the host of events that may occur asynchronously
and outside the context of a command-response exchange between host and CCID. If the
host has sent a Bulk-Out message and is waiting for a Bulk-In message in response, and
