3 01h TD2
• Higher nibble 0 means no TA3, TB3, TC3,
TD3 following.
• Lower nibble 1 means T = 1.
80h
Category indicator byte, 80h means a status
indicator may be present in an optional
COMPACT-TLV data object.
4Fh Application identifier presence indicator
LL Length
A0h
00h
00h
03h
06h
5 bytes for registered application provider
identifier (RID)
SS 1 byte for Standard
NN
NN
2 bytes for Card Name
4 to 2+n
00h
00h
00h
00h
T1
…
..
Tk
RFU: Shall be set to zero.
Assigned by PC/SC for future extensions.
3 + n UU TCK Exclusive-OR of bytes T0 to Tk
Table 14 – ATR for MIFARE
®
cards
The ATR of a contactless storage card is structured in the manner described in the table
above. In order to allow the application to identify a storage card type properly, its Standard
and Card Name bytes must be interpreted according to the following tables:
b7 b6 b5 b4 b3 b2 b1 b0 Description
0 0 0 0 0 0 0 0 No information given
0 0 0 0 0 0 1 1 ISO14443-A, part 3
0 0 0 0 0 1 0 0 ISO14443-A, part 4
… RFU
1 1 1 1 1 1 1 1 RFU
Table 15 – SS Byte for Standard
Card Name
Two bytes
identifier
MIFARE
®
Standard 1K 00h 01h
MIFARE
®
Standard 4K 00h 02h
MIFARE
®
Ultralight 00h 03h
Table 16 – NN Bytes for Card Name
