Status register (bStatus).
Slot error register: when bmCommandStatus = 1
Error Code Error Name Possible cases
FFh CMD_ABORTED Host aborted the current activity
FEh ICC_MUTE CCID time out while talking to the ICC
FDh XFR_PARITY_ERROR Parity error while talking to the ICC
FCh XFR_OVERRUN Overrun error while talking to the ICC
FBh HW_ERROR An all inclusive hardware error
occurred
F8h BAD_ATR_TS
F7h BAD_ATR_TCK
F6h ICC_PROTOCOL_NOT_SUPPORTED
F5h ICC_CLASS_NOT_SUPPORTED
F4h PROCEDURE_BYTE_CONFLICT
F3h DEACTIVATED_PROTOCOL
F2h BUSY_WITH_AUTO_SEQUENCE Automatic Sequence Ongoing
F0h PIN_TIMEOUT
EFh PIN_CANCELED
E0h CMD_SLOT_BUSY A second command was sent to a slot
which was already processing a
command
C0h to 81h User Defined Low byte of error code listed in Annex
80h and
those filling
the gaps
Reserved for future used
7Fh to 01h Index of not supported / incorrect
message parameter
00h Command not supported
Table 23 : Slot error register when bmCommandStatus = 1
Slot Status register:
Offset Field Size Value Description
0 bmICCStatus 2 bits 0, 1, 2 0 – An ICC is Present and active (power
is on and stable, RST is Inactive)
