Reference Manual Preliminary
Prox–DU & Prox–SU
www.gemalto.com Release for first samples Do not use for final design
DOC118569A Public Use Page 96/134
ERR_ATTRIB_RESP FE90h Wrong Attrib response
Wrong condition for RATS, PPS, ATTRIB T=CL or Deselect exchange
ERR_CID_NOT_FREE FE91h The CID is not free (RATS or ATTRIB)
ERR_CID FE92h
The CID is not affected to a card.
(PPS, Exchange T=CL block or Deselect)
ERR_ACTIVATE_FORBID FE93h A card is already activated with CID = 0
ERR_BIT_RATE FE94h The bit rate is not supported by the card (PPS
or ATTRIB)
Error during T=CL block exchange
ERR_TCL_PROTOCOL FE95h Infringement of protocol rule
ERR_APPLI_BUF_OVF FE96h Card response too long for the application
buffer
Error during EEPROM operations
ERR_EEPROM_CRC FE9Bh Wrong CRC check in EEPROM
Contactless interface initialization failure
ERR_NO_CTLESS FEFBh The contactless is not operational
Other codes FFxxh not listed are RFU
Table 26 : Contactless commands error code
Error label Value Meaning
Wrong state to execute the command or function (command rejected)
ERR_MFRC_AUTHENTICATION FDA1h Mifare Authentication failed
ERR_MFRC_CODE FDA2h Wrong Mifare card ACK/NAK response
ERR_MFRC_NOTAUTH FDA3h Mifare block operation not authorized
ERR_MFRC_BYTECOUNT FDA4h Wrong number of byte for Mifare read block
response
ERR_MFRC_WRITE FDA5h Mifare write error
ERR_MFRC_VAL FDA6h Mifare Inc, Dec, Restore or Transfer error
ERR_MFRC_INCR FDA7h Mifare Increment or Decrement overflow or
underflow
Table 27 : Mifare commands execution error
Error label Value Meaning
Low level card communication error
ERR_MFRC_PROTOCOL FDB1h SOF incorrect
or incorrect number of received byte
during Mifare Authentication
ERR_MFRC_FIFOOVFL FDB2h FIFO overflow
ERR_MFRC_CRC FDB3h CRC error during transmission
ERR_MFRC_COLLISION FDB4h Collision detected
ERR_MFRC_PARITY FDB5h Parity error during reception
ERR_MFRC_NY_IMPLEMENTED FDB6h Other error not implemented
ERR_MFRC_RECBUF_OVFL FDB7h Low level reception buffer overflow
ERR_MFRC_BITCOUNT FDB8h Wrong number of expected bits received
ERR_MFRC_SERNR FDB9h Wrong serial number DCC byte
ERR_MFRC_TIME_OUT FDFEh RF time out
Table 28 : Contactless exchange error codes
