Reference Manual Preliminary
Prox–DU & Prox–SU
www.gemalto.com Release for first samples Do not use for final design
DOC118569A Public Use Page 83/134
conversion factor
11 bmTCCKST0 1 00h, 02h For T=0,
b0 – 0b
b7-2 – 000000b
b1 = 0 direct convention
CCID ignores bit b1
12 bGuardTimeT0 1 00h-FFh Extra Guard Time between two
characters. Add 0 to 254 etu to the
normal guard time 12 etu. FFh is
the same as 00h
13 bWaitingIntegerT0 1 00h-FFh WI for T=0 used to define WWT
14 bCLockStop 1 00h- 03h ICC clock stop support
00h = Stopping the clock is not
allowed
Protocol data structure for protocol T=1 (bProtocolNum = 1) (dwLength = 00000007h):
Offset Field Size Value Description
10 bmFindexDindex 1 b7-4 – FI
b3-0 – DI
11 bmTCCKST1 1 10h, 11h,
12h, 13h
For T=0,
b7-2 = 000100b
b0 = 0b – Checksum LRC
b0 = 1b – Checksum CRC
b1 = 0 - direct convention
CCID ignores bit b1
12 bGuardTimeT1 1 00-FFh Extra Guard Time between two
characters. If value FFh, then
guard time is reduced by 1 etu.
13 bWaitingIntegersT1 1 00-9Fh b7-b4 = BWI value 0-9 valid
b3-b0 = CWI value 0-F valid
14 bCLockStop 1 00h- 03h ICC clock stop support
00h = Stopping the clock is not
allowed
15 bIfsc 1 01-FEh Size of negotiated IFSC
16 bNadValue 1 Value = 00h if CCID doesn’t
support a value other than the
default value.
Else the value respects ISO/IEC
7816-3 9.4.2.1
The response to this message is the RDR_to_PC_Parameters response message.
PC_to_RDR_Escape command
This command allows the CCID manufacturer to define and access extended features.
Information sent via this command is processed by the CCID control logic.
Offset Field Size Value Description
0 bMessageType 1 6Bh PC_to_RDR_Escape
1 bwLength 4 Size of the abData field
5 bSlot 1 00h Slot 0
6 bSeq 1 00-FFh Sequence number for the
command
7 abRFU 3 000000h Reserved for Future Used
10 abData Byte
array
Data block sent to the CCID
