Reference Manual Preliminary
Prox–DU & Prox–SU
www.gemalto.com Release for first samples Do not use for final design
DOC118569A Public Use Page 52/134
1 byte 1 byte
Where:
VER Version
01h
VER is used in the future to
differentiate different version of this
command.
ABLM Address Block MSB 00h
ABLL Address Block LSB
MIFARE
®
1K
MIFARE
®
4K
00h – 3Fh
00h – FFh
KT Key Type
Key A 60h
Key B 61h
KN Key Number
MIFARE
®
Key Number 0 to 159 (00h to 9Fh)
The key number 0 to 79 are
reserved for the non volatile key
stored in EEPROM
The key number 80 to 159 are
reserved for the volatile key stored in
RAM
SW1-SW2 Command execution status
Command executed
successfully
90h 00h
Others Refer to the error codes table below
The authentication is performed for a memory sector. As each memory sector is composed
of four memory blocks, the authentication will be done for all the four memory blocks.
The authentication operation is not required for a MIFARE
®
Ultralight chip.
If an authentication fails, the smart card is automatically deselected (MIFARE
®
specification). However the reader/writer automatically recovers the communication with the
smart card.
Read Binary command
The Read Binary command is used to read data from a MIFARE
®
memory block.
Data consist of a memory block (16 bytes).
This command is formatted as follows:
