Reference Manual Preliminary
Prox–DU & Prox–SU
www.gemalto.com Release for first samples Do not use for final design
DOC118569A Public Use Page 85/134
7 abRFU 3 000000h Reserved for Future Used
The response to this message is the RDR_to_PC_SlotStatus response message.
Response pipe bulk-in messages for the contactless
interface
The following CCID messages are implemented for the contactless interface:
• RDR_to_PC_DataBlock
• RDR_to_PC_SlotStatus
• RDR_to_PC_Parameters
• RDR_to_PC_Escape
The following CCID message is not implemented:
• RDR_to_PC_DataRateAndClockFrequency
RDR_to_PC_DataBlock Command
This message is the response to the PC_to_RDR_IccPowerOn and the
PC_to_RDR_XfrBlock command messages.
For the PC_to_RDR_PowerOn commande message this response message contains the
pseudo ATR data associated with the contactless card.
For the PC_to_RDR_XfrBlock command message this response message contains the card
response.
If the card is a T=CL card: the card response is send “as it”. (Only the data of the INF field of
the T=CL block).
If the card is a MIFARE
®
card: the card response is the data read in the card followed by a
status word SW1SW2 or only the status, according to the PC/SC specification.
Offset Field Size Value Description
0 bMessageType 1 80h RDR_to_PC_DataBlock
1 bwLength 4 Size of the abData field
5 bSlot 1 00h Slot number : Same as Bulk-Out
message
6 bSeq 1 00-FFh Sequence number : Same as Bulk-
Out message
7 bStatus 1 00h, 01h,
02h, 40h,
41h, 42h,
80h
Slot status register:
0Xh = no error
4Xh = command failed
80h Time extension request
X = 0 card present and active
X = 1 card present and inactive
X = 2 card not present
8 bError 1 00h-FFh Slot error register:
Error when bStatus = 4Xh
Time multiplier when bStatus =
0x80h
9 bChainParameter 1 00h Depends on the exchange level
reported by the class descriptor in
dwFeature field.
Short APDU level, this field is RFU
= 00h
10 abData Byte This field contains the data
