8. Place the battery by putting front catches in grooves and move the battery forward
until that the rear catches clicks. The battery can be ejected by pressing side catchers.
Battery installing
9. Close UAV top cover and make sure that locking pin hold it.
Top cover closing
Propeller blades, wing and elevon surfaces must not be damaged or cov-
ered with any kind of paint, dirt or stickers. Changing of UAV parts may
cause mid-ight malfunction and damage.
16
