7. Place the launcher on at surface. The UAV must be launched against the wind.
UAV launch is allowed only against the wind. It is strictly forbidden to launch the UAV in
the direction of the wind. Otherwise, the UAV will not be able to correctly gain altitude
and may collide with objects on the way.
Make sure that the launcher is stable on the ground and that its guide has no roll.
8. Install and hammer stopping peg into the hole at the rear part of the launcher to
prevent displacements when the UAV starts.
The jerk of the wire springs leads to the throwing of the launcher’s rear part, when the
UAV starting. You must hammer on the stop peg on the entire length to x the launcher’s
rear part. Don’t to deform the launcher, when you hammer on the stop peg.
9. Place springs’ tube on the bottom of launcher and attach as shown on the picture.
Sprigs’ tube attaching
37
