Gerber HS15 Plus - Page 76

HS15
plus
REFERENCE CARD
KEY/FUNCTION DESCRIPTION
SWIVEL KNIFE Key
Press
SWIVEL KNIFE
to select swivel knife mode (light above the key is on) or press
again to select tangential knife mode (light above the key is off).
INIT KNIFE Key
Press INIT KNIFE to initialize the swivel knife so it is in a known position (blade
faces 0°) before every job or after changing material.
HS15
plus
TOOL FORCE SETTINGS REFERENCE CARD
Material Recommended
Starting Tool
Force
Tangential
Knife Blade
HS Plotter
Swivel Knife
Controltac 180
Delux 210 Gold/Silver
Dusted Crystal 210 .05-1
30
°
42
°
Florescent 210
Scotchcal

220
Translucent 230
GerberCal

Gerber IP Plus

GerberMask

I & II
1
30
°
42
°
Heat Transfer Flock
Hot Split Plastisol
Metalized Polyester
Screen Print .05
30
°
42
°
Static Cling
Sandblast 521 4-5
45
°
or 60
°
Sandblast 522
Pouncing paper 5-6 (
pounce wheel
)
Plotting paper .5-1 (
pen
)
Gerber Field Service Department 800-828-5406
Outside the USA please fax: 203-645-2448
