Handheld Tester Emulator Test Suite Worksheet
3
PAGE 115
[P] [F] L. Access mode test: All steps must occur in the prescribed order to pass:
1. Verify that the HO_AVBL signal is ON on the equipment
2. Place the equipment into manual access mode using the equipment user interface. Note:
the equipment should also have this functionality using the host instead of the user interface,
but this is not part of the test plan.
3. Verify that the HO_AVBL signal is OFF
4. Place the equipment into automated access mode using the equipment user interface.
5. Verify that the HO_AVBL signal is ON
Notes:
Handheld Tester Emulator Test Suite Worksheet
3
PAGE 116
[P] [F] M. Port sensors tied into E84 signals part 1 - Placement sensor(s)activated during Load, but
presence sensor(s) is not: All steps must occur in the prescribed order to pass:
1. Verify that the HO_AVBL signal is ON on the equipment
2. Set the CS_0 signal ON and CS_1 signal OFF on the E84 HHT
3. Set the VALID signal ON on the E84 HHT
4. Verify that the equipment turns the L_REQ signal ON
5. Set the TR_REQ signal ON on the E84 HHT
6. Verify that the equipment turns the READY signal ON
7. Set the BUSY signal ON on the E84 HHT and activate all of the placement sensor(s) only on
the loadport associated with the E84 interface being tested
8. Verify that the equipment does NOT turn the L_REQ signal OFF
9. After exceeding the TP3 time, verify that the equipment indicates a TP3 timeout error on the
User Interface
Notes:
