Handheld Tester Emulator Test Suite Worksheet
3
PAGE 117
[P] [F] N. Port sensors tied into E84 signals 2 - Presence sensor(s) activated during Load, but
placement sensor(s) is not: All steps must occur in the prescribed order to pass:
1. Verify that the HO_AVBL signal is ON on the equipment
2. Set the CS_0 signal ON and CS_1 signal OFF on the E84 HHT
3. Set the VALID signal ON on the E84 HHT
4. Verify that the equipment turns the L_REQ signal ON
5. Set the TR_REQ signal ON on the E84 HHT
6. Verify that the equipment turns the READY signal ON
7. Set the BUSY signal ON on the E84 HHT and activate the presence sensor(s) only on the
loadport associated with the E84 interface being tested
8. Verify that the equipment does NOT turn the L_REQ signal OFF
9. After exceeding the TP3 time, verify that the equipment indicates a TP3 timeout error on the
User Interface
Notes:
Handheld Tester Emulator Test Suite Worksheet
3
PAGE 118
[P] [F] O. Port sensors tied into E84 signals 3 - Placement sensor(s) deactivated during Unload, but
presence sensor(s) is not: All steps must occur in the prescribed order to pass:
1. Activate both the placement and presence sensors on the loadport associated with the E84
interface being tested
2. Verify that the HO_AVBL signal is ON on the equipment
3. Set the CS_0 signal ON and CS_1 signal OFF on the E84 HHT
4. Set the VALID signal ON on the E84 HHT
5. Verify that the equipment turns the U_REQ signal ON
6. Set the TR_REQ signal ON on the E84 HHT
7. Verify that the equipment turns the READY signal ON
8. Set the BUSY signal ON on the E84 HHT and deactivate the placement sensor(s) only from the
loadport associated with the E84 interface being tested
9. Verify that the equipment does NOT turn the U_REQ signal OFF
10. After exceeding the TP3 time, verify that the equipment indicates a TP3 timeout error on the
User Interface
Notes:
